该户型受结构影响并不能进行较大户型爆改，客户需要和户型结构图进行了局部微调，餐厅采用活动是多功能餐桌，根据需求进行调整，原则是让人感觉客厅比较宽敞。现在我们根据效果 一起聊聊全案水电布置需要注意什么。 This huxing can not be affected by the structure of the larger huxing blasting, customers need and huxing structure Diagram for local fine-tuning, the restaurant is a multi-functional dining table, according to the need for adjustment, the principle is to make people feel more spacious living room. Now we according to the effect, talk about the whole case of water and electricity layout needs to pay attention to what.
平面布置图
本案采用当下比较流行的水走天，电走地，横平竖直石膏固定，底盒和线管采用配套螺栓链接施工工艺。 This case uses the current more popular water walk days, electric walk, horizontal and Vertical Gypsum fixed, bottom box and pipeline using matching bolt link construction technology.
厨房水电改造注意事项：下水管一定要做隔音处理，水槽下一定要预留下足够的后期增加设备的插座，比如净水机、软水机、洗碗机、垃圾处理机等，一般2-3个插座可以满足基本需求。另外根据需要在调整，最关键干完电路，一定把不要的插座孔线路好封好，这样贴完砖就比较好看。反之您就知道，怎么让您的高端墙砖变成地摊货。 Kitchen Water and electricity transformation notes: The sewage pipe must do sound-proof processing, under the sink must reserve enough later period increases the equipment socket, like the water purifier, the water softener, the dishwasher, the garbage disposal machine and so on, general 2-3 socket can meet the basic needs. In addition, according to the need to adjust the most critical dry circuit, be sure to put a good seal of the socket line, so pasted brick is better. Otherwise, you will know how to make your high-end wall tiles into a bargain.
主卧电路改造：效果图和电路布置对比，您就明白专业和非专业的区别，我们改造要求的是点对点的布线，不允许中间有截头。注意的还是多余的插座和改动不要的一定接好线条，直接封好。施工完成您会感谢我的。 Master Bedroom Circuit Transformation: Effect Diagram and circuit layout comparison, you will understand the difference between professional and non-professional, we require the transformation is point-to-point wiring, do not allow the middle section. Note that the extra socket and do not change must be connected to a good line, directly sealed. You’ll thank me when it’s done.
次卧和主卧一样，点对点我们采用大湾工艺方便后期线路 有问题方便维修。这一点也非常重要。 The second bedroom, like the master bedroom, is point-to-point, and we use the Grand-Baie process to facilitate late-stage wiring, with problems to facilitate maintenance. This is also very important.
卫生间水路电路改造和厨房一样下水管做隔音处理，冷热水管做保温处理，防止冷凝水和南方梅雨季水管上洁水。如果采用暗装就不需要做 保温。 The water circuit of the toilet is reformed and the same as the kitchen. The water pipes are soundproofed, and the cold and hot pipes are heat-insulated to prevent the condensation water and the clean water on the water pipes during the rainy season in south China. No need to do it if you are wearing it in dark. Keep it warm.
最后一定要做水管打压试验，这非常总要。到此一套全案水电改造第一步就结束。欢迎大家一起探讨。 Finally, be sure to do a water pipe pressure test, which is very important. This is the first step of a complete set of hydropower transformation. I welcome you all to discuss.
